Rifle Scope Product Details
TAC Vector Optics Hunting Riflescope Forester 1-5×24 2-10×40 3-15×50 Edgeless Image 4″ Long Eye Relief Rifle Scope Return to Zero Adjust FD7 Reticle
Model: SCOC-03
Magnification: 1-5x
Objective Lens Dia: 24mm
Ocular Lens Dia: 33mm
Exit Pupil: 24-4.8mm
Optics Coating: Fully-multi coated
Field of View: 73.3-19.9 feet @ 100 yards
Eye Relief : 115-95mm (4.5-3.7″)
Length: 265mm (10.4 inch)
Weight: 415g (14.6oz)
Tube Dia.:30mm Monotube
Click Value: 1/2 MOA
Parallax Setting: 50 yards
Reticle: Etched glass VFD-2
Model: SCOM-02
Magnification: 2-10x
Objective Lens Dia: 40mm
Ocular Lens Dia: 33mm
Exit Pupil: 20-4.0mm
Optics Coating: Fully-multi coated
Field of View: 41.9-10.47 feet @ 100 yards
Eye Relief: 100-90mm (4.0-3.5″)
Length: 340mm (13.4 inch)
Weight: 500g (17.6oz)
Tube Dia.:30mm Monotube
Click Value: 1/4 MOA
Parallax Setting: 50 yards
Reticle: Etched glass VFD-2
Model: SCOM-16
Magnification: 3-15x
Objective Lens Dia: 50mm
Ocular Lens Dia: 33mm
Exit Pupil: 16.7-3.3mm
Optics Coating: Fully-multi coated
Field of View: 36.2-7.2 feet @ 100 yards
Eye Relief: 95-85mm (3.7-3.3″)
Length: 385mm (15.1 inch)
Weight: 575g (20.3oz)
Tube Dia.:30mm Monotube
Click Value: 1/4 MOA
Parallax Setting: 100 yards
Reticle: Etched glass VFD-2, super thin
Ocular Lens Length: 80mm
Elevation Range: 60 MOA
Windage Range: 60 MOA
Illumination: 11 levels red
Battery: CR2032(NOT INCLUDED)
Number of Lens: 12 pcs
Shock tested to 750g, water proof at 300 meters and 54 degree
Fully nitrogen purged to eliminate any fogging of the lenses internally
Adjust plate is NOT fixed, after zero the scope you can turn the plate to zero
High quality 6061 T6 aircraft grade aluminum
Designed for close and mi-range shooting
Diopter compensation from fast-focus eyepiece (+2 to -2)
Including items: 30mm weaver mount rings (default) or dovetail mount ring (on request only), cleaning cloth, lens cap, packaged in nice retail box
Rifle Scope Product Features
Edgeless Image Image, Super Bright Clear
Return to Zero Adjustment Plate
4″ Long Eye Relief,1/4′ Adjustment,30mm Monotube,FD7 Style Etched Glass Reticle
Shock tested to 750g, water proof at 300 meters and 54 degree
Including items: 30mm weaver mount rings (default) or dovetail mount ring (on request only), cleaning cloth, Instruction, lens cap, packaged in nice retail box
About the TAC Vector Optics Brand
TAC Vector Optics is a premium producer for long gun scopes, optics, mounting solutions, and other components used for firearms like rifles and long guns. They innovate and build their products by applying elements which are durable and long lasting. This includes the TAC Vector Optics Hunting Riflescope Forester 1-5×24 2-10×40 3-15×50 Edgeless Image 4″ Long Eye Relief Rifle Scope Return to Zero Adjust FD7 Reticle by TAC Vector Optics. For more shooting products, visit their site.
Information About Rifle Scopes
Rifle scopes permit you to exactly aim a rifle at various targets by lining up your eye with the target over a distance. They accomplish this through magnification by employing a set of lenses inside the scope. The scope’s alignment can be adapted for the consideration of numerous environmental considerations like wind and elevation decreases to account for bullet drop.
The scope’s purpose is to understand precisely where the bullet will hit based on the sight picture you are seeing via the scope as you line up the scope’s crosshair or reticle with the target. Most modern rifle scopes and optics have around eleven parts which are arranged inside and externally on the scope. These scope parts consist of the rifle scope’s body, lenses, windage and elevation dials, focus rings, and other components. Learn about the eleven parts of rifle scopes.
Rifle Optic Types
Rifle scopes can be either “first focal plane” or “second focal plane” type of scopes. The sort of focal plane an optic has determines where the reticle or crosshair is located relative to the optic’s magnifying adjustments. It literally indicates the reticle is situated behind or ahead of the magnifying lens of the optic. Deciding on the most reliable style of rifle optic is based upon what sort of hunting or shooting you anticipate undertaking.
Info About First Focal Plane Glass
Focal plane scopes (FFP) feature the reticle in front of the magnification lens. These styles of scopes are useful for:
- Quick acquisition, far away kinds of shooting
- Shooting circumstances where estimations are very little
- Experienced shooters who know their target “hold over” as well as “lead” ratios for their long gun
- Shooters who don’t mind the reticle is enlarged and uses up more visual sight space than a SFP reticle
About Second Focal Plane Optics
Second focal plane glass (SFP) come with the reticle to the rear of the zoom lens. This causes the reticle to stay at the very same scale in relation to the volume of magnification being used. The effect is that the reticle dimensions change based on the magnification chosen to shoot over lengthier ranges due to the fact that the markings present various increments which vary with the zoom level. In the FFP illustration with the SFP optic, the 5x “zoom” one hundred yard tick reticle measurement would be 1/5th of the non “zoom” tick. These types of optics are useful for:
- Far away styles of shooting where shooters have additional time to make ballistic estimations
- Shooting where most shots take place within much shorter ranges and proximities
- Shooters who like a clearer optic picture with less space used up by the enlarged FFP reticle
Rifle Glass Zoom
The quantity of zoom a scope provides is determined by the size, thickness, and curvatures of the lenses inside of the rifle scope. The magnification of the scope is the “power” of the scope.
Fixed Single Power Lens Optic Details
A single power rifle optic comes with a zoom number designator like 4×32. This indicates the magnification power of the scope is 4x power and the objective lens is 32mm. The zoom of this kind of optic can not fluctuate given that it is a fixed power optic.
Adjustable Power Lens Rifle Glass
Variable power rifle scopes have adjustable power. These types of scopes will list the zoom level in a format such as 2-10×32. These numbers imply the zoom of the scope could be set between 2x and 10x power. This additionally involves the powers in-between 2 and 10. The power modification is achieved by making use of the power ring component of the scope near the back of the scope by the eye bell.
Power and Range Correlations
Here are some suggested scope power settings and the distances where they can be successfully used. Always remember that high magnification optics will not be as efficient as lower magnification level optics since too much magnification can be a bad thing. The exact same idea relates to longer distances where the shooter needs to have enough power to see precisely where to properly aim the rifle.
Lens Finish for Rifle Glass
All modern rifle scope and optic lenses are layered. There are various types and qualities of coverings. When considering luxury rifle optics and scope devices, Lens finishing can be a significant component of defining the rifle’s capability. The lenses are one of the most vital pieces of the optic considering that they are what your eye sees through while sighting a rifle in on the target. The finishing on the lenses protects the lens surface area and improves anti glare from excess sunshine and color presence.
HD Versus ED Optic Lens Coatings
Some scope manufacturers also use “HD” or high-definition lens finishings which use different techniques, chemicals, components, and polarizations to draw out separate colors and viewable definition through the lens. Some scope makers use “HD” to refer to “ED” to signify the lens has extra-low dispersion glass.
Single Covering Versus Multi-Coating
Different optic lenses can also have different coatings used to them. All lenses typically have at least some type of treatment or coating applied to them prior to being used in a rifle scope or optic.
This lens treatment can protect the lens from scratches while lowering glare and other less beneficial things experienced in the shooting environment while sighting in with the scope. The quality of a single covered lens depends on the scope producer and how much you paid for it.
Some scope manufacturers likewise make it a point to specify if their optic lenses are coated or “multi” coated. This means the lens has had numerous treatments applied to the surfaces. If a lens gets several treatments, it can show that a producer is taking several steps to combat various natural aspects like an anti-glare covering, a scratch resistant anti-abrasion finishing, followed by a hydrophilic finishing. This also doesn’t always indicate the multi-coated lens is better than a single layered lens. Being “much better” hinges on the producer’s lens treatment technology and the quality of glass used in constructing the rifle optic.
Anti-water Lens Finishes
Water on a lens does not improve retaining a clear sight picture through an optic in any way. Lots of top of the line and high-end scope makers will coat their lenses with a hydrophobic or hydrophilic coating. The Steiner Optics Nano-Protection is a fine example of this type of treatment. It treats the surface area of the Steiner glass lens so the H2O particles can not bind to it or create surface tension. The result is that the water beads sheet off of the scope to keep a clear, water free sight picture.
Rifle Scope Installation Alternatives
Mounting options for scopes are available in a couple of options. There are the standard scope rings which are individually mounted to the optic and one-piece mounts which cradle the scope. These different types of mounts also usually come in quick release versions which use toss levers which permit rifle operators to quickly mount and dismount the optics.
Hex Key Rifle Glass Rings
Basic, clamp type mounting optic rings use hex head screws to mount to the flattop design Picatinny scope mounting rails on rifles. These kinds of scope mounts use a pair of detached rings to support the optic, and are usually constructed from 7075 T6 billet aluminum or similar materials which are developed for long distance accuracy shooting. This type of scope mount is excellent for rifles which need to have a long lasting, hard use mount which will not change no matter just how much the scope is moved about or jarring the rifle takes. These are the style of mounts you should have for a devoted optics system on a far away scouting or hard target interdiction firearm which will almost never need to be modified or recalibrated. Blue 242 Loctite threadlocker can also be used on the scope mount screws to stop the hex screw threads from wiggling out after they are mounted firmly in place. An example of these mounting rings are the 30mm type made by the Vortex Optics company. The set normally costs around $200 USD
Rifle Scope Mounts with Quick-Release Cantilever Rings
These types of quick-release rifle scope mounts can be used to quickly connect and remove a scope from a rifle before reattaching it to a different rifle. Multiple scopes can even be swapped out if they all use a compatible design mount. These types of mounts come in handy for rifle platforms which are transferred a lot, to remove the optic from the rifle for protecting the scope, or for scopes which are used in between multiple rifles.
What to Know About Rifle Scope Tube Sealing and Gas Purging
Wetness inside your rifle optic can mess up a day of shooting and your costly optic by causing fogging and creating residue within the scope tube. Most optics prevent wetness from entering the optical tube with a system of sealing O-rings which are waterproof. Usually, these water resistant scopes can be submerged within 20 or 30 feet of water before the water pressure can force moisture past the O-rings. This should be more than enough wetness prevention for conventional use rifles, unless you plan on taking your rifle on boats and are worried about the scope still performing if it is submerged in water and you can still salvage the firearm.
Gas Purged Rifle Optic Tubes
Another part of avoiding the buildup of wetness within the rifle scope’s tube is filling the tube with a gas like nitrogen. Given that this space is currently occupied by the gas, the glass is less influenced by temperature level alterations and pressure distinctions from the outside environment which could possibly permit water vapor to seep in around the seals to fill the vacuum which would otherwise exist. These are good qualities of a good rifle scope to look for.
